Spring Lock Washers Coil Rolling Machine

Description

Description

Main Specifications of Spring Lock Washers Coil Rolling Machine:

Model Spring Washer Size Motor(KW) Weight(TON) Dimension(CM)
SPC-5 M3-M5 1.5 0.4 138*60*98
SPC-6 M6 1.5 0.5 160*65*95
SPC-10 M8-M10 3 0.8 180*75*135
SPC-16 M12-M16 4 1 180*75*135
SPC-22 M18-M22 5.5 1.2 200*145*90
SPC-30 M24-M30 5.5 1.6 220*100*150
SPC-48 M30-M48 11 2 260*110*180

Application Scope

The Spring Lock Washer Coil Rolling Machine is to coiling the flatten wire by core rod,make the faltten wire like spring type and then cut by cutting machine for finished spring lock washer.

Salient Features of Spring Lock Washer Coil Rolling Machine

1. The automatic running with plc control.
2. Wire drawing speed is fast and drawed flatten wire surface bright and top appearance.
3. Easy to operate and less power consumption.

Main Structure and Designs


Standard accessories of Spring Lock Washer Coil Rolling Machine

1. One set of standard hand tools.
2. One set of control Panel
3. Inside Lamp

Running video of Spring Lock Washer Coil Rolling Machine
